About charging:
300w: Standard 14.6v5A charger, option foldable solar panel 18V 100W
500W: Standard 14.6v8A charger, option foldable solar panel 18V 100W
1000W: Standard 14.6v12A (Can be upgraded to 20A charger), option foldable solar panel 18V 100W
2000W: Standard AC plug cable, option foldable solar panel 18V 300W
3000W: Standard 29.2V 10A charger, option foldable solar panel 36V 400W
5000W: Standard 58.4V 15A charger, option foldable solar panel 72V 600W
You can choose whether need the charger according to your needs (the standard includes a charger by default, but no solar panel). We can configure complete solar system for you. If you need, Please contact us.
300W
| 300W PORTABLE POWER STATION | ||
| Input | 1.DC5521:14.6V/5A,70W Charger Input | |
| 2.DC5521:Supports Photovoltaic Solar 15V-24V 5A Input,50W-100W | ||
| 3.The two DC5521 Ports can only charge or discharge at the same time, not one charge and other discharge at the same time. | ||
|
AC Output 110V/220V |
AC Output Voltage: AC Output Ports*2 AC 220V±5% | |
| AC Output Watt: 300W | ||
| Over-load Protection:310W~450W | ||
| AC Output wave: Pure sine wave | ||
| AC Output Peak: 600W peak hold time<50ms | ||
| Frequency: 50Hz | ||
| Type-C1 Output | TYPE-C: QC3.0 MAX 12V/1.5A (18W) PD MAX | |
| USB Output | USB-A1: | QC3.0 MAX 12V/1.5A(18W) |
| USB-A2: | MAX 5V/3A(15W) | |
| USB-A3: | ||
| DC Output | DC-1/DC-2 12V10A(120W) MAX | |
| Led Light Output | Support Strong/Weak/SOS Flashing three-speed switching output | |
| Horn | Maximum output power: 5W | |
| Bluetooth Version | 5.4 | |
| Battery Type | Grade A LiFePO4 Lithium Iron Battery | |
| Battery Capacity | 216wh | |
| Battery Cycle | Over 4000 Cycles | |
| Product Dimensions | 278*129*215mm | |
| Weight | 3.09KG | |
| Protect Function | Short Circuit, Over-load, Over-heat, Over-voltage, Over-current, Shor-voltage | |
| Charging time | 2-3H from 10% to 100%(auto cut-off) | |
| Charging voltage | 14.6V+0.1V the voltage until full-charge | |
|
* OPERATION INSTRUCTIONS: * POWER ON: Press and hold the DC key for 1 second to turn on the entire system and the LED display screen will light up when the system is turned on. * BLUETOOTH SPEAKER: Turn on the USB key, Open Bluetooth on your phone, find the Bluetooth device named"CHUYI”, and click to connect. and to play music! |
||
500W
| 500W PORTABLE POWER STATION | ||
| Input | 1. DC: 6A | |
| 2. XT60: 8A MAX 10A supports photovoltaic MPPT tracking (Single machine)within 100W. DC5521 is no shared with XT60 | ||
|
AC Output 110V/220V |
AC Output Voltage: AC Output Ports*3, AC 220V±5% | |
| AC Output Watt: 500W | ||
| AC Output wave: Pure sine wave | ||
| Frequency: 50Hz | ||
| Wireless Charging Output | 15W | |
| Type-C Output | TYPE-C: | PD MAX 18W |
| USB Output | Fast Charge: | MAX 18W (Blue) |
| USB-A1: | 5V2A | |
| USB-A2: | ||
| USB-A3: | ||
| USB-A4: | ||
| DC Output | Cigar Lighter: | 8A |
| DC: | 6A | |
| Led Light Output | 3W, Support Strong/SOS Flashing two modes switching output | |
| Battery Type | Grade A LiFePO4 Lithium Iron Battery | |
| Battery Capacity | 432wh | |
| Battery Cycle | Over 4000 Cycles | |
| Product Dimensions | 300*210*260mm | |
| Weight | 5.61KG | |
| Protect Function | Short Circuit, Over-load, Over-heat, Over-voltage, Over-current, Shor-voltage | |
| * MCU software alarm prompt, over-pressure and low-pressure alarm/shutdown, intelligent temperature control | ||
1000W
| 1000W PORTABLE POWER STATION | ||
| Input | 1. DC: 6A | |
| 2. XT90: 14.6V MAX 30A supports photovoltaic MPPT tracking (Single machine)within 100W. DC5521 is no shared with XT90 | ||
|
AC Output 110V/220V |
AC Output Voltage: AC Output Ports*4, AC 220V±5% | |
| AC Output Watt: 1000W | ||
| AC Output wave: Pure sine wave | ||
| Frequency: 50Hz | ||
| Wireless Charging Output | 15W | |
| Type-C Output | TYPE-C: | PD MAX 18W |
| USB Output | Fast Charge: | MAX 18W |
| USB-A1: | 5V2A | |
| USB-A2: | ||
| USB-A3: | ||
| USB-A4: | ||
| DC Output | Cigar Lighter: | 8A |
| DC-1: | 6A | |
|
|
DC-2: | |
| Led Light Output | 3W, Support Strong/SOS Flashing two modes switching output | |
| Battery Type | Grade A LiFePO4 Lithium Iron Battery | |
| Battery Capacity | 1440wh | |
| Battery Cycle | Over 6000 Cycles | |
| Product Dimensions | 405*262*270mm | |
| Weight | 12.01KG | |
| Protect Function | Short Circuit, Over-load, Over-heat, Over-voltage, Over-current, Shor-voltage | |
| * MCU software alarm prompt, over-pressure and low-pressure alarm/shutdown, intelligent temperature control | ||
2000W
| 2000W PORTABLE POWER STATION | ||
| Input | 1. DC5521: 10V~45V/10A supports photovoltaic MPPT tracking,DC5521 is shared with XT60, and cannot be inserted at the same time, 50-400W | |
| 2. XT60: 10V~45V MAX 400W supports photovoltaic MPPT tracking,DC5521 is shared with XT60, and cannot be inserted at the same time, 50-400W | ||
| 3. AC Input Ports: 180V~250V, rated power 1000W | ||
|
AC Output 110V/220V |
AC Output Voltage: AC Output Ports*2 AC 220V±5% | |
| AC Output Watt: 2000W | ||
| AC Output wave: Pure sine wave | ||
| Frequency: 50Hz | ||
| Wireless Charging Output | 15W | |
| Type-C Output | TYPE-C1: |
PD MAX 12V/1.5A (18W) PD MAX 12V/2.5A (30W) |
| TYPE-C2: | PD MAX 20V/5A(100W). When TYPE-C2 and USB-A1 are plugged in at the same time, the total output is 5V/5A | |
| USB Output | USB-A1: | QC3.0 MAX 20V/3A (60W). When TYPE-C2 and USB-A1 are plugged in at the same time, the total output is 5V/5A |
| USB-A2: | QC3.0 MAX 12V/1.5A (18W) | |
| DC Output | Cigarette Lighter: | 12V/10A 120W Total Power |
| DC-1: | ||
| DC-2: | ||
| Led Light Output | Power: 4W, Support Strong/Weak/SOS Flashing three-speed switching output | |
| Battery Type | Grade A LiFePO4 Lithium Iron Battery | |
| Battery Capacity | 2592wh | |
| Battery Cycle | Over 4000 Cycles | |
| Product Dimensions | 460*250*340mm | |
| Weight | 23.42KG | |
| Protect Function | Short Circuit, Over-load, Over-heat, Over-voltage, Over-current, Shor-voltage | |
|
* OPERATION INSTRUCTIONS: * Touchable Screen, Detailed parameter display. * Power On: Touch the screen, press and hold the power button for 1 second, the system will turn on, and the screen saver will stay on. |
||
